Finisher C4/C5
Service Manual Ver.1.6
施乐复印机装订器分页器Finisher C4,C5英文维修手册1.6版本
Issued with the introduction of the new Apeos C7070/C6570/C5570/C4570/C3570/C3070/C2570, ApeosPro C810/C750/C650 and Apeos C8180/C7580/C6580
Revision by adding information (Chapter 4 Adjustments, Chapter 6 Specifications, Chapter 9 Installation)
Revision of Chapter 9 by adding information
Issued with the introduction of the new Apeos 5570/4570
Revised due to WW suppor
Revised with the introduction of ApeosPrint C5570
Revised with the introduction of Apeos 7580/6580
011-101 MBX Vertical Sensor ON Jam (MBX M/C ONLY)
BSD-on: CH44.82
Description
The MBX Vertical Sensor did not turn ON within the specified time.
DC330 Codes for checking:
[013-192] MBX Vertical Sensor
[013-091] MBX Transport Motor
[013-081] MBX Gate Solenoid
Check the following Bin Solenoids when a jam occurs.
[013-082] 2Bin Gate Solenoid
[013-083] 3Bin Gate Solenoid
[013-084] 4Bin Gate Solenoid
[013-085] 5Bin Gate Solenoid
[013-086] 6Bin Gate Solenoid
[013-087] 7Bin Gate Solenoid
[013-088] 8Bin Gate Solenoid
[013-089] 9Bin Gate Solenoid
[013-090] 10Bin Gate Solenoid
Check Items
Clean the light emitter/light receptor of the MBX Vertical Sensor.
Check the feed section of the Roller for wear, dirt, or scratches.
Transport failure due to out-of-spec paper.
Remove any foreign matter in the feed section.
